| Model | A | C | D | E | G | H | I | K | M |
| WKG-1000 | 1780 | 720 | 1820 | 2000 | 3150 | 360 | 1120 | 270 | 820 |
| Model | Applicable machine（TON） | Up/Down Travel (MM) | Front/Rear Travel (MM) | Horizontal Travel (MM) | Weight (KG) | Max Load (KG) |
| WKG-1000 | 250T-400T | 1000 | 800 | 1700 | 280 | 12-20 |
High-precision motion control
Equipped with high-precision servo motors, achieving position accuracy of ±0.05mm and repeatability of ±0.02mm. The speed is adjustable up to 10m/s for maximum production flexibility.
Stable and reliable mechanical structure
Constructed with high-strength aluminum alloy and steel, the design ensures rigidity, reduces vibration, and maintains performance under heavy-load, high-speed operation.
Intelligent operation and maintenance
Features a user-friendly interface for easy programming. Modular design allows for quick maintenance, fault diagnosis, and reduced downtime.
Benefits to injection molding machines
- 1Improve production efficiency: Increases productivity by 30%-50% compared to manual operation.
- 2Reduce production costs: Lowers labor requirements and minimizes material waste through precision handling.
- 3Improve product quality: Ensures consistent surface quality and dimensional accuracy.
- 4Improve working environment: Safe operation in high-temperature and harsh conditions.
- 5Realize automated production: Enables stable, continuous, and intelligent unmanned production.
Technology R&D
Factory
Frequently Asked Questions
Q What tonnage is the WKG-1000 compatible with?
It is designed for injection molding machines from 250T to 400T.
Q What is the positioning accuracy?
The arm achieves a high precision of ±0.05mm and repeatability of ±0.02mm.
Q What materials is it built with?
High-strength aluminum alloy and premium steel for rigidity and low vibration.
Q How does it reduce costs?
By automating labor-intensive tasks and reducing product damage rates.
Q Is it hard to maintain?
No, it features a modular design and an intuitive interface for simple daily maintenance.
